One-tap autofill authentication templates | Developer Documentation

curl 'https://graph.facebook.com/v25.0/<WHATSAPP_BUSINESS_ACCOUNT_ID>/message_templates' \
-H 'Content-Type: application/json' \
-H 'Authorization: Bearer EAAJB...' \
-d
'{
  "name": "<TEMPLATE_NAME>",
  "language": "<TEMPLATE_LANGUAGE>",
  "category": "authentication",
  "message_send_ttl_seconds": <TIME_T0_LIVE>, // Optional
  "components": [
    {
      "type": "body",
      "add_security_recommendation": <SECURITY_RECOMMENDATION> // Optional
    },
    {
      "type": "footer",
      "code_expiration_minutes": <CODE_EXPIRATION> // Optional
    },
    {
      "type": "buttons",
      "buttons": [
        {
          "type": "otp",
          "otp_type": "one_tap",
          "text": "<COPY_CODE_BUTTON_TEXT>",  // Optional
          "autofill_text": "<AUTOFILL_BUTTON_TEXT>", // Optional
          "supported_apps": [
            {
              "package_name": "<PACKAGE_NAME>",
              "signature_hash": "<SIGNATURE_HASH>"
            }
          ]
        }
      ]
    }
  ]
}'

curl 'https://graph.facebook.com/v25.0/102290129340398/message_templates' \
-H 'Content-Type: application/json' \
-H 'Authorization: Bearer EAAJB...' \
-d '
{
  "name": "authentication_code_autofill_button",
  "language": "en_US",
  "category": "authentication",
  "message_send_ttl_seconds": 60,
  "components": [
    {
      "type": "body",
      "add_security_recommendation": true
    },
    {
      "type": "footer",
      "code_expiration_minutes": 10
    },
    {
      "type": "buttons",
      "buttons": [
        {
          "type": "otp",
          "otp_type": "one_tap",
          "text": "Copy Code",
          "autofill_text": "Autofill",
          "package_name": "com.example.luckyshrub",
          "signature_hash": "K8a/AINcGX7"
        }
      ]
    }
  ]
}'

./sms_retriever_hash_v9.sh --package "com.example.myapplication" --keystore ~/.android/debug.keystore

dependencies {…
    implementation 'com.whatsapp.otp:whatsapp-otp-android-sdk:1.0.0'…}

repositories {…
    mavenCentral()…}

<activityandroid:name=".ReceiveCodeActivity"android:enabled="true"android:exported="true"android:launchMode="standard"><intent-filter><actionandroid:name="com.whatsapp.otp.OTP_RETRIEVED"/></intent-filter></activity>

publicclassReceiveCodeActivityextendsAppCompatActivity{@Overrideprotectedvoid onCreate(Bundle savedInstanceState){super.onCreate(savedInstanceState);WhatsAppOtpIncomingIntentHandler incomingIntentHandler =newWhatsAppOtpIncomingIntentHandler();// Retrieve the expected handshake ID that was stored during handshake initiationString expectedHandshakeId = retrieveStoredHandshakeId();

          incomingIntentHandler.processOtpCode(
                                 getIntent(),
                                 expectedHandshakeId,(code)->{// The handshake ID has been validated by the SDK
                                   validateCode(code);},// call your function to handle errors(error, exception)-> handleError(error, exception));}

publicclassReceiveCodeActivityextendsAppCompatActivity{@Overrideprotectedvoid onCreate(Bundle savedInstanceState){super.onCreate(savedInstanceState);Intent intent = getIntent();// Extract the handshake ID from the intentString incomingRequestId = intent.getStringExtra("request_id");// Retrieve the previously stored handshake IDString storedRequestId = retrieveStoredRequestId();// Validate the handshake ID matchesif(storedRequestId !=null&& storedRequestId.equals(incomingRequestId)){// use OTP codeString otpCode = intent.getStringExtra("code");// ...}}}

WhatsAppOtpHandler whatsAppOtpHandler =newWhatsAppOtpHandler();
UUID handshakeId = whatsAppOtpHandler.sendOtpIntentToWhatsApp(context);// Store handshakeId to validate the received OTP code later

privateString currentRequestId;publicvoid sendOtpIntentToWhatsApp(){// Generate a unique handshake ID
   currentRequestId = UUID.randomUUID().toString();// Store this ID for later validation when receiving the OTP
   storeRequestId(currentRequestId);// Send OTP_REQUESTED intent to both WA and WA Business App
   sendOtpIntentToWhatsApp("com.whatsapp", currentRequestId);
   sendOtpIntentToWhatsApp("com.whatsapp.w4b", currentRequestId);}privatevoid sendOtpIntentToWhatsApp(String packageName,String requestId){/**
  * Starting with Build.VERSION_CODES.S, it will be required to explicitly
  * specify the mutability of  PendingIntents on creation with either
  * (@link #FLAG_IMMUTABLE} or FLAG_MUTABLE
  */int flags =Build.VERSION.SDK_INT >=Build.VERSION_CODES.S ? FLAG_IMMUTABLE :0;PendingIntent pi =PendingIntent.getActivity(
      getApplicationContext(),0,newIntent(),
      flags);// Send OTP_REQUESTED intent to WhatsAppIntent intentToWhatsApp =newIntent();
  intentToWhatsApp.setPackage(packageName);
  intentToWhatsApp.setAction("com.whatsapp.otp.OTP_REQUESTED");// WA will use this to verify the identity of the caller app.Bundle extras = intentToWhatsApp.getExtras();if(extras ==null){
     extras =newBundle();}
  extras.putParcelable("_ci_", pi);// Add the handshake ID for secure validation
  intentToWhatsApp.putExtra("request_id", requestId);
  intentToWhatsApp.putExtras(extras);
  getApplicationContext().sendBroadcast(intentToWhatsApp);}

WhatsAppOtpHandler whatsAppOtpHandler =newWhatsAppOtpHandler();

If(whatsAppOtpHandler.isWhatsAppInstalled(context)){// ... do something}

if(this.isWhatsAppInstalled(context)){// ... do something}publicboolean isWhatsAppInstalled(final@NonNullContext context){return isWhatsAppInstalled(context,"com.whatsapp")||
           isWhatsAppInstalled(context,"com.whatsapp.w4b");}publicboolean isWhatsAppInstalled(final@NonNullContext context,final@NonNullString type){finalIntent intent =newIntent();
    intent.setPackage(type);
    intent.setAction("com.whatsapp.otp.OTP_REQUESTED");PackageManager packageManager = context.getPackageManager();List<ResolveInfo> receivers = packageManager.queryBroadcastReceivers(intent,0);return!receivers.isEmpty();}}

let schemeURL = URL(string:"whatsapp://otp")!let isWhatsAppInstalled =UIApplication.shared.canOpenURL(schemeURL)

curl -L 'https://graph.facebook.com/v25.0/105954558954427/messages' \
-H 'Content-Type: application/json' \
-H 'Authorization: Bearer EAAJB...' \
-d '{
      "messaging_product": "whatsapp",
      "recipient_type": "individual",
      "to": "12015553931",
      "type": "template",
      "template": {
        "name": "verification_code",
        "language": {
          "code": "en_US"
      },
      "components": [
        {
          "type": "body",
          "parameters": [
            {
              "type": "text",
              "text": "J$FpnYnP"
            }
          ]
        },
        {
          "type": "button",
          "sub_type": "url",
          "index": "0",
          "parameters": [
            {
              "type": "text",
              "text": "J$FpnYnP"
            }
          ]
        }
      ]
    }
  }'
